RH5 M A 0900M 01 D70 1 S 1 0 1 1 G 6 R-Series V Position Sensors Industrial Position Sensors Temposonics®
RH5 M A 0900M 01 D70 1 S 1 0 1 1 G 6 R-Series V Position Sensors Industrial Position Sensors Temposonics®
Regular price
$2,699.00 USD
Regular price
Sale price
$2,699.00 USD
Shipping calculated at checkout.
R-Series V Position Sensors
Industrial Position Sensors
Temposonics® magnetostrictive linear position sensors feature all relevant industry outputs to support a large variety of industrial applications. This, together with the reliability of the position and velocity measurement, guarantees superior control of the application.
Developed for linear position measurement in industrial applications
Stroke lengths from 25 mm to 20 m
Various sensor models, designs, outputs, approvals and performance classes are available
NENN (Order code)
RH5 M A 0900M 01 D70 1 S 1 0 1 1 G 6
SCHNITTSTELLE (Interface)
SSI
BF (Sensor model)
RH5: Rod
AB (Flange)
M: Threaded flange M18×1.5-6g (standard)
MO (Mechanical options)
A: Standard
ME (Unit of measurement)
M: Metric - Millimeters
MLVERS (Stroke length version)
Stroke length Standard
ML (Stroke length)
900.0
MNR (Number of magnets)
01: 1
ANS (Connection type)
D70: M16 male connector (7 pin)
SYS (System)
1: Standard
AG (Output)
S: SSI
FN (Function)
1: Position
OPT (Options)
0: Standard
BS (Output range)
-
MD (Mode)
1: Measuring direction forward, asynchronous mode
DL (Data length / bit)
1: 25
KOD (Format)
G: Gray
AL (Resolution / mm)
6: 0,002
AO (Additional options (optional))
-
MX (Max speed or velocity value (optional)) 0
DESC1 (Detailed description)
The R-Series V RH5 rod-type sensors are designed for direct position
measurement in hydraulic or pneumatic cylinders. With an operating
temperature of up to +85°C, excellent shock and vibration resistance, and a
pressure resistance of up to 800 bar, the RH5 sensor ensures extremely accurate
position measurement even under extreme conditions. The sensor's modular
design makes it easy to replace the sensor element and electronics with the
hydraulic circuit closed for service. This not only eliminates leaks, but also saves
on maintenance costs and significantly reduces downtime. It is available in
lengths from 25 to 7620 mm. The sensor is CE, UL/CUL, EAC and UKCA
certified.
DESC2 (Detailed description)
The SSI output provides an extremely stable measurement with a minimum
resolution of 0.1 µm. In addition, the sensor offers an asynchronous mode and
three different synchronous modes to match the measurement to the control
cycle. The sensor also provides linear extrapolation, allowing a cycle time of
100 μs or a data readout rate of up to 10 kHz to be achieved for any
measurement length of the sensor. The R-Series V-SSI can also detect and
output the difference between 2 magnets. When combined with the TempoLink
or TempoGate sensor assistant, additional information beyond position
measurement can be captured.
