*Image shown is a representation only. Actual product may vary*
85311070, VK 100F10T5A93D
Type: Motorized valve for gas
For automatic shut-off, closed when de-energized, slow opening, quick closing, for natural gas, town gas, LPG and air, also suitable for biologically produced methane and landfill gas, Class A to EN 161, EU certified
Nominal diameter: DN 100
Pipe connection: Flange to ISO 7005
Inlet pressure: pu max. 1 bar
Mains voltage: 220/240 V~, 50 Hz
Valve housing: AlSi
Electrical connection: Metal terminal connection box, IP 54
Pressure test point: Screw plugs at the inlet and outlet
Flow adjustment: Yes
weight 22kg
